The RE is responsible of updating this table in all installed PFE. Also referred as FIB - Forwarding information base. Contains all the active (best) routes from the RT.
Also referred as RIB - Routing information base. It is located in the RE and updated by routing protocols. It has three primary functions: switch data between the line cards, control the chassis, and house the routing engine (RE is usually inserted into this card). Implements various services such as policing, stateless firewall filtering, and class of service. Uses Layer 2 and Layer 3 forwarding tables to forward traffic toward its destination. PFE - Packet Forwarding Engine, the intelligent component of the forwarding plane.It is a set of linecards interconnected by a switch fabric, that together represent the forwarding plane (also called the data plane). The internal link has a built-in rate limiter that is not configurable and protects against DoS attacks. Is connected to the line cards with an internal ethernet switch ( show chassis ethernet switch). Processes exception traffic (routing protocol updates, management traffic for the RE an packets with IP options). Has a kernel, it is an x86 with flash, SSD and RAM. RE - Routing engine - Responsible for OSPF, SSH, etc.Usually implemented on a Routing Engine (RE) Control plane - The control plane is the router's brain and its computational element.Contrail - SDN controller for network management and orchestration from the cloud.IP/MPLSView is a multivendor, multiprotocol, and multilayer operations support systems (OSS) traffic management and traffic engineering solution for IP and/or MPLS networks.It automates the control of segment routing and IP/MPLS flows.
NorthStart Controller - SND controller for traffic engineering (optimization).Virtualized security appliance with native SRX Series software. OCX - recent switches, focused on open, disaggregated networking systems.Firewall, switch, WiFi, 3G, VoIP, Routing. ACX Series - Universal Access Router - optimized for metro network architecture, access aggregation, LTE deployments, mobile backhaul.High bandwidth, for core, Tbps throughput. J series - used for small offices and have integrated security (similar to SRX but older).MX Series - universal routing platform used for routing and also switching.T Series - no switching, only routing, old, performance upgrade for M.M Series - first product by Juniper Networks, multiservice router (routing and MPLS services, no switches) Designed for enterprise and service providers.Author: Anton Chmutov Derevianko Product portfolio Routers
